Accessories > Motors > Outrunner Brushless Motor
|
|
|
TOPEDGE 2835 Outrunner Brushless Motor-KV900
|
|
|
| Item No: |
OB2835-09 |
| Packing Size: |
134*46*46mm |
| Gross Weight: |
95g |
| Brand: |
TOPEDGE |
|
|
|
|
|
| Description |
|
Specifications:
KV: 900
Resistance: 0.1023¦¸
Non-load Current: 0.6A
Working Current: ¡Ü20A
Shaft Diameter: 4mm
N.W.: 68g
G.W.: 95g
Parameters:
| KV |
Non-load
Current |
Max
Working Current |
Loaded
Propeller |
Input
Voltage |
Working
Current |
Pull |
Output Power |
Rated Current |
Weight |
Shaft
(mm) |
Internal
Resistance |
| 900 |
0.6A |
20A |
1047 |
11.1V |
13.5A |
1010g |
149.8w |
17A |
68g |
4 |
0.1023 |
| 12V |
14.5A |
1135g |
174w |
| 14V |
17A |
1360g |
238w |
| 16.8V |
21A |
1600g |
352.8w |
| 1147 |
8.4V |
12A |
830g |
100.8w |
| 11.1V |
17A |
1180g |
188.7w |
| 14V |
22A |
1410g |
308w |
| 1340 |
7.4V |
9.5A |
600g |
70.3w |
| 8.4V |
11A |
800g |
92.4w |
| 11.1V |
16A |
1000g |
177.6w |
| 12.6V |
18.5A |
1400g |
233.1w |
| 14.8V |
23.8A |
1800g |
352.2w |
Size Reference:
Unit: mm
|
|
